Smart Thermostat Installation Guide
Less than 1 hour
Easy to install yourself
Installing your Smart Thermostat is really simple. If you’ve installed a light or a switch before, this will be child’s play! Quick and simple, it takes less than an hour to install it in your home.
Check compatibility
Several installation options
Fixed on the wall (wired option)
Your Smart Thermostat can be installed on the wall. It will replace your existing wired thermostat and can be easily installed in the same place.
Placed on a shelf or cabinet (wireless option)
Your Smart Thermostat can also be installed without any wires. You can simply place it wherever you want and move it at any time!
Pack contents
- 4 coloured adhesives
- 1 Smart Thermostat
- 1 Relay
- 3 AAA batteries
- 1 installation manual
- 1 wall mounting plate (132 x 132mm)
- 4 screws and 4 anchors
- 1 mains adapter
- 1 mobile stand and 1 wall-bracket
- 1 boiler adapter
Compatible with most individual heating systems
Heat pump
Check the compatibility of my heatingInstallation requirements
a personal Wi-Fi network
A heat pump - heating only
Underfloor heating
Check the compatibility of my heatingInstallation requirements
a personal Wi-Fi network
one of these energy sources: Gas, Oil, Wood, Heat pump
an individual heating system
Several heating zones
Check the compatibility of my heatingInstallation requirements
an individual heating system with several thermostats
a personal Wi-Fi network
one of these energy sources: Gas, Oil, Wood, Heat pump
Apartment with collective heating, with a thermostat
Check the compatibility of my heatingInstallation requirements
a personal Wi-Fi network
an individual thermostat at the entrance to the apartment
Boiler
Check the compatibility of my heatingInstallation requirements
a personal Wi-Fi network
one of these energy sources: Gas, Oil, Wood, Heat pump
An individual boiler
Adapts to all situations
You’re replacing a wired thermostat
In this system, the Netatmo Thermostat is installed on the wall and controls your boiler through the existing electrical wires.The Thermostat communicates via radio with the Netatmo relay.This ensures Wi-Fi connection to the internet and remote control from the Netatmo app.
You’re replacing a wireless thermostat
In this system, the Netatmo relay is connected to your boiler and controls your heating.It communicates via radio with the Netatmo Thermostat that you use to set the temperature.The relay ensures the Wi-Fi connection to the internet and remote control from the Netatmo app.
You’re installing your first thermostat
In this system, the Netatmo relay is connected to your boiler and controls your heating.It communicates via radio with the Netatmo Thermostat that you use to set the temperature.The relay ensures the Wi-Fi connection to the internet and remote control from the Netatmo app.
FAQ
Is my system compatible?
Your heating equipment is compatible with Netatmo Smart Thermostat if it respects the following criteria:
• Switching current: max 120VA (4A load @ 30V, 1A load @ 110V/120V or 0,5A load @ 220V/240V)
• 2 wires dry contact (ON/OFF)
• Power factor: cos φ > 0.8
Check your compatibility on check.netatmo.com
What’s the maximum distance between a Smart Thermostat and Relay?
Up to 100 metres in an open space. We recommend placing the Relay in a central room in your home.
How is the Smart Thermostat powered?
The Thermostat uses 3 AAA batteries (provided). They have a battery life of 2 years. The Relay is connected to the mains either via the boiler adapter or a conventional socket.
Can I manage a multi-zone installation?
Yes, if the system has several heating circuits (e.g., ground floor and 1st floor). Each zone must be regulated by either a Smart Thermostat, a Smart Modulating Thermostat or Smart Radiator Valves, depending on the installation type. This means you can set different temperatures for different zones for greater comfort and energy savings.
Can you create more than one heating schedule/programme?
Yes, you can create up to 10 heating schedules.
Which product should I choose: a Smart Thermostat or a Smart Thermostatic Starter Pack ?
If you have an individual heating system, then a Smart Thermostat is required to control your boiler activation.
If you install a Starter Pack onto an individual boiler system, it will not be able to control the boiler and will not have any effect in terms of energy savings.
